QInsight Documentation

Welcome to the QInsight tutorial. These pages walk you step by step through QInsight — the desktop environment of the QENEX Suite platform — from the very first simple simulation project all the way to a real ECU measured, calibrated and stimulated over XCP.

Live data, calibration and stimulation of a real ECU from one workspace — that is exactly what the XCP on TCP and XCP on CAN examples walk you through.

Where to go next

• Getting started — What is QENEX Suite and your first project in a few minutes.
• Connecting a device — drivers, protocols and wiring them to variables.
• Complete examples — the projects from the Examples folder next to QInsight.exe, from a simulation without hardware through Modbus master and slave over a serial line and TCP to XCP on TCP and XCP on CAN on a real ECU (measurement, stimulation and calibration maps), plus bit field and a script, two ECUs at once, JSON signals from Python and Raw CAN from a Raspberry Pi.
• Automation — Python scripts in the project, at runtime and during data analysis.
• SDK & extensions — the QFW SDK for the device side and custom drivers, protocols and Controls.

Start with What is QENEX Suite.
